제품소개

HOME > 제품소개 > 레벨측정(Level)
제품목록
Photos Product Name Description Model Catalogue
Float switches with permanent magnet/Vertical mounting Float switches with permanent magnet/Vertical mounting Explosion-protected version
Guide tube diameter : 12~18mm
Float material : Stainless steel(Buna, titanium)
Operating temperature : -196~300℃
 RSM catalog_462e045027fe57538b2b13c47b98712a0.pdf
Electronic level switch with display Electronic level switch with display Range : 0~189 to 684mm
Output : 2 switching & 4~20mA, 0~10V
Accuracy : 1.0%
Display : 14-segment LED, 4-digit
Medium temperature : -20~80℃
Approvals : CE		 LSD-30 catalog_3a409bfa616694466620cb3023fb4a570.pdf
Optoelectronic level limit switches Optoelectronic level limit switches Mini limit switches
Output : PNP OC trnasistor
Accuracy : 0.5mm
Temperature range : -30~140℃
 LSO.02 catalog_c2186d6bf644b52c6256efc0bddb23bf0.pdf
Optoelectronic level limit switches Optoelectronic level limit switches Explosion-protected version
Measuring length : 0~25 to 800mm
Accuracy : 0.5mm
Temperature range : -269~400℃
Working pressure : Max.500bar		 LSO.06 catalog_13aca2845b33e896e50573c51b978aa80.pdf
Switching amplifier Switching amplifier Selectable versions
- 19" plug-in card
- in mounted case
Output : Signal relay, SPDT		 LOS.25 catalog_f6d2efe3243a86cbe979d024fc42a83a0.pdf
Float switches with permanent magnet/Horizontal mounting Float switches with permanent magnet/Horizontal mounting Explosion-protected version
Insertion length : 190~1090mm
Contact tube length : 100~1000mm
Float diameter : 44mm, 52mm
Operating temperature : -196~350℃
 HIF catalog_2fac98cc3c39af302d7fe3bba2423b8f0.pdf
Float switches with permanent magnet/Lateral mounting Float switches with permanent magnet/Lateral mounting Explosion-protected version
Float material : Stainless steel
Guide tube diameter : 12mm
Operating temperature : -30~300℃
 RSB catalog_f5e5f0394bc4ff7d9a8431254bf478040.pdf
Bypass level indicator with magnetic roller display Bypass level indicator with magnetic roller display Explosion-protected version
C to C : 150~6000mm
Operating temperature : -160~450℃
Working pressure : max. 420bar		 BNA catalog_7ad2a87aa0bbd279adc37e409dea217a0.pdf
Sight glass level indicator Sight glass level indicator Operating temperature : -200~450℃
Pressure rating : PN 6~250		 LGG catalog_071f4dc22b64c0bcd7dfcaed0b2bff6b0.pdf
Magnetostrictive level sensor Magnetostrictive level sensor Explosion-protected version
Guide tube diameter : 12, 18mm
Accuracy : 0.5mm
Temperature range : -200~200℃
Working pressure : Max.100bar		 FFG catalog_49bfc4ec39ece99c426a633f30ab13300.pdf
Reed switch chain level sensor Reed switch chain level sensor Explosion-protected version
Guide tube diameter : 12, 18mm
Accuracy : 0.5mm
Temperature range : -80~200℃
Working pressure : Max.100bar		 RMG catalog_46f05df4ba9b783e0d32c1f26b5ee08f0.pdf
